ENGINE

• Engine: 850 E-TEC
• Engine details: Liquid-cooled, two-stroke, 3-D R.A.V.E.
• Cylinders: 2
• Displacement: 849 cc
• Bore: 82 mm
• Stroke: 80.4 mm
• Maximum engine speed: 7900 RPM
• Carburation: Electronic Direct Injection with additional booster injectors
• Recommended fuel type: Unleaded
• Minimum octane: 95
• Fuel tank: 42 L / 11 gal
• Oil tank capacity (2-stroke): 3.4 L / 3.6 qt

POWERTRAIN

• Drive clutch type: pDrive with clickers
• Driven clutch type: QRS
• Brake system: Hydraulic brake with braided steel brake line, plastic master cylinder

DIMENSION

• Vehicle Overall Length: 127 in.
• Vehicle Overall Width: 47.2 in.
• Vehicle Overall Height: 48.4 in.
• Ski Stance: 39 in.
• Track Length x Width x Profile: PowderMax : 154 x 20 x 2.4 in.

COLOUR

• Platinum Silver Satin / Evo Red

SUSPENSION

• Front suspension: LFS+
• Front shock: KYB PRO 36 EA-3 R Kashima
• Rear suspension: EasyRide +
• Center shock: KYB 46 Plus Kashima
• Rear shock: KYB 46 Plus Kashima

FEATURES

• Frame: Radien-X
• Skis: Blade DS+
• Seating: Brutal, 1-up
• Handlebar: U-type aluminium with hooks, low grab handle
• Riser block height: 120 mm
• Starter: Electric and manual
• Reverse: RER
• Heated grips: Standard
• Heated throttle lever: Standard
• Gauge: 7.2-in. wide digital display
• Visor Plug front / rear: Front
• Windshield: Low
• 12V power outlet: Yes, in front compartment
• LinQ Attachment: Multi-LinQ plate
