Outboard system with remote steering and remote throttle that is 80-hp equivalent
A synthesis of performance and a perfectly integrated overall system with a ground-breaking safety concept that sets Deep Blue apart from all other electric drive systems on the market
All the components of the system are perfectly engineered to match each other and are completely watertight
We provide a 9-year warranty on the Deep Blue's battery capacity
Electric boat propulsion is not only powerful and safe, it is also a genuine commercial alternative for heavy users
Special group tariff from Pantaenius Yacht Insurance with improved insurance protection and lower premiums compared with the normal tariff for boats with other high-voltage drives
Transparent maintenance overhead An electric drive system requires far less maintenance than comparable drive systems using fossil fuel
Shaft length: 51 cm (short shaft) / 63.5 cm (long shaft)
Technical Data Deep Blue
Deep Blue System
Deep Blue 80RL / RXL
Input power (continuous) in kW
55.1
Propulsive power in kW
32.4
Comparable petrol outboards (shaft power)
80 HP
Maximum overall efficiency in %
54
Motor weight without battery, including electronics in kg
139 (L) / 145 (XL)
Shaft length
20" / 51 cm (L) 25“ / 63.5 cm (XL)
Standard propeller v = speed in km/h at p = power in watts
v50/p50k
Maximum propeller speed in rpm
2.400
Control
Throttle
Tilting device
Electric trim and tilt
Trim device
Electric trim and tilt
Integrated on-board computer with touchscreen display
