For riders who want on and off trail versatility with the smooth and powerful 650 Patriot engine.
FEATURES
Rider first design. Effortless control: The Switchback on the Matryx platform is a boondockers dream. The narrow cockpit provides improved rider connection to the sled. Helping you move around the sled in deep snow for balance or on-trail for precision.
Float. Fly. And Carve the Corners: The IGX 146 Rear Suspension features optimized geometry to better control pitch. Tipped rail design gives you the flotation benefit of a 146 suspension, with the trail manners of a 137 suspension.
Smooth. Powerful. Fuel Efficient: Built on the proven architecture of the 850 Patriot, the 650 Patriot is smooth, powerful and features instant throttle response.
ENGINE & DRIVETRAIN
Bore x Stroke: 74.8 mm x 74 mm
Cylinders Displacement: 2 - 650 cc
Disc Brake Type: MATRYX Stealth
Drive System Type: Chaincase
Drive/Driven Clutch: P-85 / TEAM LWT
Engine Type / Cooling: Liquid Cooled
Exhaust: Single, 3 Stage VES
Fuel System: Cleanfire Injection
Ignition: Patriot 3DS
DIMENSIONS
Estimated Dry Weight: 508 lb (230 kg)
Fuel Capacity: 11.5 gal (43.5 L)
Overall Height: 54.5 in (138.4 cm)
Overall Length: 125 in (317.5 cm)
Overall Width: 47 in (119.4 cm)
Person Capacity: 1
Ski Center Distance: 42.5 in (108 cm)
SUSPENSION
Front Shocks: Polaris IFP
Front Suspension: MATRYX Front Suspension
Front Track Shock: Polaris IFP
Front Travel: 9.5 in (24.1 cm)
Rear Suspension: PRO-CC
Rear Track Shock: Polaris IFP
Rear Travel: 16 in (40.6 cm)
Ski Type: PRO-STEER
Track Width / Length / Height (in): 15 x 146 x 1.6" Cobra
