The Switchback Assault delivers incredible flotation and traction in deeper snow with on-trail capability.
FEATURES
Rider First Design. Effortless Control: The Switchback on the Matryx platform is a boondocker's dream. The narrow cockpit provides improved rider connection to the sled. Helping you move around the sled in deep snow for balance or on-trail for precision.
Float. Fly. And Carve the Corners: The IGX 146 Rear Suspension features optimized geometry to better control pitch. Tipped rail design allows for easier cornering and acceleration while the 146" length offers improved flotation.
Choose Your Power: With three engine choices from the Patriot Family. Choose a smooth and powerful 650, industry-leading power-to-weight 850, or the turbocharged Factory Mod… the Patriot Boost.
ENGINE & DRIVETRAIN
Bore x Stroke: 85 mm x 74 mm
Cylinders Displacement: 2 - 840 cc
Disc Brake Type: MATRYX Stealth
Drive System Type: Chaincase
Drive/Driven Clutch: P-85 / TEAM LWT
Engine Type / Cooling: Liquid Cooled
Exhaust: Single, 3 Stage VES
Fuel System: Cleanfire Injection
Ignition: Patriot 3DS
DIMENSIONS
Estimated Dry Weight: 508 lbs / 230 kg
Fuel Capacity: 11.5 gal (43.5 L)
Overall Height: 54.5 in (138.4 cm)
Overall Length: 125 in (317.5 cm)
Overall Width: 47 in (119.4 cm)
Person Capacity: 1
Ski Center Distance: 42.5 in (108 cm)
SUSPENSION
Front Shocks: WER 2" Velocity
Front Suspension: MATRYX Front Suspension
Front Track Shock: WER 2" C/A
Front Travel: 9.5 in (24.1 cm)
Rear Suspension: IGX 146
Rear Track Shock: WER Velocity
Rear Travel: 16 in (40.6 cm)
Ski Type: PRO-STEER
Track Width / Length / Height (in): 15 x 146 x 1.352" Cobra, 15 x 146 x 1.5" Ice Storm, 15 x 146 x 1.6" Cobra, 15 x 146 x 2.0" Crossover
