A crossover trail sled designed to deliver the confidence to make your day on the snow the best it can be.
FEATURES
Durable. Light. Nimble: The Pro-Ride chassis is a proven platform. Strong and light.
Floats off-trail. Comfortable On-trail: The 144 Coil-Over Rear Suspension is designed for better flotation and deep snow performance with an improved on-trail ride. By eliminating the torsion springs and redesigning the torque arms, the skid weighs substantially less.
Durable, reliable performance: The Liberty 550 engine is fan-cooled to provide consistent power, regardless of snow conditions. The clutching is equipped for smooth engagement and enhanced low-speed drivability.
ENGINE & DRIVETRAIN
Bore x Stroke: 73 mm x 65 mm
Cylinders Displacement: 2 - 544 cc
Disc Brake Type: RMK Hydraulic
Drive System Type: Chaincase
Drive/Driven Clutch: CVTECH PowerBloc50 / Invance
Engine Type / Cooling: Fan Cooled
Exhaust: Single
Fuel System: Carbureted
Ignition: CDI
DIMENSIONS
Estimated Dry Weight: 452 lb (205 kg)
Fuel Capacity: 11.5 gal (43.5 L)
Overall Height: 48 in (122 cm)
Overall Length: 124 in (315 cm)
Overall Width: 48 in (122 cm)
Person Capacity: 1
Ski Center Distance: 42.5 in (108 cm)
SUSPENSION
Front Shocks: Polaris IFP
Front Suspension: PRO-RIDE
Front Track Shock: Polaris IFP
Front Travel: 7.1 in (18 cm)
Rear Suspension: INDY
Rear Track Shock: Polaris IFP
Rear Travel: 14.1 in (35.8 cm)
Ski Type: PRO-STEER
Track Width / Length / Height (in): 15 x 144 x 1.35" Cobra
